Cessna Cessna 172 (1963–1974) Used acceptable

AN3-15A

BOLT

2 Qty / Assembly
4 Aircraft
327 IPC Page
About this part

Part number AN3-15A is a BOLT used in the Cessna 150 (1963–1969) and 3 other aircraft, cataloged on IPC page 327. This part is also referenced in the Cessna 150 (1970–1977) and Cessna 172 (1963–1974) and Cessna 182 (1974–1976) parts catalogs. Standard hardware — used is fine if undamaged and within spec.

IPC Diagram — Page 327
Illustrated parts diagram for AN3-15A (BOLT), IPC page 327
Part Specifications
Part NumberAN3-15A
DescriptionBOLT
Qty per Assembly2
Aircraft Cessna 150 (1963–1969), Cessna 150 (1970–1977), Cessna 172 (1963–1974), Cessna 182 (1974–1976)
IPC Page327
Buying Advice
Used acceptable

Standard hardware — used is fine if undamaged and within spec.

Where to Buy
Find on eBay Find on Amazon
Related Parts — AN3 Family
AN3-3AAN3-4AN3-19AAN3-10AAN3-17AAN3-13A

View all AN3 variants →

Also on IPC Page 327
0500210-28 REAR SEAT INSTALLATION-INDIVIDUALLY RECLINING BACK 0500210-125 BOTTOM ASSEMBLY-REAR SEAT 0500210-113 BOTTOM ASSEMBLY-REAR SEAT 0500210-139 BOTTOM ASSEMBLY-REAR SEAT 0500210-162 BOTTOM ASSEMBLY-REAR SEAT 0514082-4 BOTTOM ASSEMBLY-REAR SEAT 0514082-19 BOTTOM ASSEMBLY-REAR SEAT 0514090-11 BOTTOM ASSEMBLY-REAR SEAT
