Cessna Cessna 172 (1963–1974) Used acceptable

AN815-6

UNION

1 Qty / Assembly
2 Aircraft
533 IPC Page
About this part

Part number AN815-6 is a UNION used in the Cessna 150 (1963–1969) and 1 other aircraft, cataloged on IPC page 533. This part is also referenced in the Cessna 172 (1963–1974) parts catalogs. Standard hardware — used is fine if undamaged and within spec.

IPC Diagram — Page 533
Illustrated parts diagram for AN815-6 (UNION), IPC page 533
Part Specifications
Part NumberAN815-6
DescriptionUNION
Qty per Assembly1
Aircraft Cessna 150 (1963–1969), Cessna 172 (1963–1974)
IPC Page533
Buying Advice
Used acceptable

Standard hardware — used is fine if undamaged and within spec.

Where to Buy
Find on eBay Find on Amazon
Related Parts — AN815 Family
AN815-4MAN815-30AN815-40AN815-3DAN815-5AN815-50

View all AN815 variants →

Also on IPC Page 533
0521559-8 FUEL SYSTEM INSTALLATION LINE ASSEMBLY-VENT S14850GSL CLAMP S1493-6 HOSE ASSEMBLY-FUEL BULC ITEM REF S-1495-6-3.30 S1891-6 ATTACHING PARTS CLAMP 0500118-80 LINE ASSEMBLY-VENT USED WITH LONG RANGE TANKS S1591-2 HARNESS BAND UC 0500106-83 LINE ASSEMBLY-FUEL TANK 0500118-42 LINE ASSEMBLY-UNION TO UNION LH
